This amplifier module achieves peak power at an operating voltage of 16Vdc with a 4Ω loudspeaker. With lower voltages and higher resistance loudspeakers, power will increase accordingly. If the signal source has a low output power (e.g. a microphone), it will be necessary to connect a pre-amplifier (i.e. Order Code M040) between the source & the potentiometer.

Available accessory: M040 Universal Preamplifier

Technical data:

• Musical power: max. 40W at 4 Ohm loudspeaker load -voltage of 16V
• Operating voltage: 6...16V
• Connectable loudspeakers: 4...8 Ohm
• Sensitivity: < 500mV
• Frequency range: approx. 20...25.000 Hz
• Dimensions: approx. 70 x 45 x 29 mm
